An Orifice plate assembly provides maximum economy with minimum maintenance. It consists of orifice plate, studs, nuts, jack bolts & gaskets. Flanges are according to ANSI, DIN, JIS standards. Type of orifice flanges includes Welds neck, Slip on, RTJ and T & G.
| Line size | 15-1500mm (1/2"-60" NB) |
| Pressure tap | Flange tap, Corner tap, Radius tap (D & D/2 TAP) |
| Accuracy | ±1% |
| Material of Flange | ASTM A105, A182 GR.F11, A182 GR.F22, SS304, SS316 |
